Name: 6A2 Vitrified Bond Diamond Grinding Wheel 150x40x40x5 for PCD Form Grinding
Brand: ZHENGZHOU SHINE ABRASIVES CO.,LTD
SKU: 6A2-150x40x40x5x10
Price: 82.00 USD
Availability: InStock

Home Products Vitrified Bond Wheels

6A2 Vitrified Bond Diamond Grinding Wheel 150x40x40x5 for PCD Form Grinding

Product Details:

Place of Origin:	Henan, China
Brand Name:	JC / OEM
Certification:	ISO 9001:2015
Model Number:	6A2-150x40x40x5x10

Payment & Shipping Terms:

Minimum Order Quantity:	2 Pieces
Price:	USD 45-120 / Piece
Packaging Details:	Export-grade carton with shock-proof foam insert, each wheel individually wrapped
Delivery Time:	5-10 working days for stock, 20-30 days for production
Payment Terms:	T/T,L/C,PayPal,Western Union
Supply Ability:	5000 Pieces per Month

Contact Now

Detailed Product Description

Model:	6A2	Dimensions:	150 X 40 X 40 X 5 (10/15/20) X 10 Mm
Diamond Grit:	W10 (W1.5-W40 Optional)	Bond Type:	Vitrified (Ceramic) Bond
Linear Speed:	16-50 M/s	Infeed:	0.05 Mm Per Pass
Feed Speed:	80-130 Mm/min	Applied Workpiece:	PCD / PCBN / CVD Tools
Highlight:	Vitrified Bond Diamond 6A2 Wheel , PCD Form Grinding Precision , Good Surface Quality Retention

6A2 Vitrified Bond Diamond Grinding Wheel for PCD Form Grinding

This 6A2 vitrified bond diamond grinding wheel (150x40x40x5x10, W10 grit) is engineered for precision form grinding of PCD, PCBN and superhard cutting tools. The ceramic bond keeps the wheel profile stable while delivering a superior surface finish.

Key Features

Sharp form retention keeps complex profiles accurate over long runs
Low grinding temperature avoids thermal damage to PCD edges
Outstanding workpiece precision and surface quality
High wear resistance lowers overall grinding cost

Applications

Suitable for form grinding and profile grinding of PCD inserts, PCBN tools, CVD diamond tools and cemented carbide on CNC tool grinders.

Specifications

Model	6A2
Dimensions	150 x 40 x 40 x 5 (10/15/20) x 10 mm
Diamond Grit	W10 (on request W1.5-W40)
Bond	Vitrified (Ceramic) Bond
Linear Speed	16-50 m/s
Infeed	0.05 mm per pass
Feed Speed	80-130 mm/min

Why Choose Us

Precision profiling and strict quality control ensure repeatable finishing performance. Custom grits and shapes are available. Inquire now for bulk pricing.
