| Place of Origin: | China |
| Brand Name: | Shine Abrasives |
| Certification: | ISO |
| Model Number: | 4V2 1A1 14A2 9A3 12V9 |
| Minimum Order Quantity: | 2 pcs |
|---|---|
| Price: | FOB |
| Packaging Details: | one in paperbox |
| Delivery Time: | 5 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 PCS in one week |
| Arbor Size: | 5/8 Inch, 1 Inch | Abrasive Depth: | 1/4 Inch |
|---|---|---|---|
| Wheel Hole Number: | Varies | Wheelwidth: | 10mm |
| Wheel Bond: | Resin | Speed: | High |
| Wheel Color: | Varies | Quality: | High |
| Bonding: | Vitrified,metal | Viscosity: | Good |
| Grain Size: | Customized | Cooling Method: | Dry, Wet |
| Style: | 1V1 | Structure: | Dense |
| Abrasion Resistance: | High | ||
| Highlight: | 12V9 resin bond diamond wheel,diamond grinding wheel for carbide knives,sharpening wheel for carbide tools |
||
12V9 resin diamond grinding wheel is mainly used for cylindrical grinding and cutting edge processing of cemented carbide.It is suitable for grinding metal and non-metal hard and brittle materials with low iron content,such as cemented carbide,high alumina porcelain, optical glass, agate gemstone, semiconductor material, ceramics, stone, etc.
| D | T | H | X | V | |||
| mm | Inch | mm | Inch | state bore dimension | mm | Inch | 70° |
| 75 | 3 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| 100 | 4 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| 125 | 5 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| 150 | 6 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| Other dimensons are available on request | |||||||
Resin diamond grinding wheel for sharpening carbide tools are used for tungsten carbide, high speed steel (HSS), stainless drill,end mill and reamer. We will provide a complete solution for tools manufacturing process, including fluting, gashing and clear edge, relief angle grinding .
![]()
Contact Person: Lenny Li
Tel: 008615003895611
