1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel

1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel

  • 1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel
  • 1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel
  • 1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel
  • 1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel
1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 4V2 1A1 14A2
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: one in paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 PCS in one week
Contact Now
Detailed Product Description
Features: High Efficiency, Long Life, Good Shape Retention Max Pressure: 0.2MPa
Coolant: Water Or Oil Wheel Color: Varies
Max Temperature: Customized Workpiece Material: Glass, Ceramics, Stone, Concrete, Etc.
Wheel Thickness: 1-2 Inches Size: 30mm-600mm
Durability: High Max Speed: 35m/s
Quantity: High Roughness: Smooth
Hs Code: 8207901000 Hole Size: 20mm-127mm
Max Operating Temperature: Customized
Highlight:

Diamond cutting Wheels

,

Metal Bond cutting Wheels

,

1A1R Diamond CBN Cutting Wheels

1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel

Diamond Cut-off Wheels are used for efficient cutting of hard, short-chipping and wear resistant materials such as glass, ceramics and carbide, graphite, quartz, ferrite and semiconductor materials.
CBN Cut-off Wheels are used for cutting materials with an affinity for carbon, such as iron-based alloys. High-alloy steels such as HSS and chrome steel with 12% Cr. , hardened steel from 55 HRC and magnetic materials. Soft, long-chipping materials accumulate in the chip space, so they are tend to clog. Compromises can be achieved with electroplated bonds.



Diameter (D) Abrasive Thickness (T/U) Hole Diameter (H) Abrasive Width (X)
60, 75, 80 0.3, 0.5, 0.6 10, 20 5
100 0.5, 0.6, 0.8, 1.0, 1.2 10, 20, 22, 31.75, 32 5, 10
125 0.8, 1.0, 1.2, 1.5 20, 22, 31.75, 32 5, 10
150 0.8, 1.0, 1.2, 1.5 20, 22, 31.75, 32 5, 10
180 0.8, 1.0, 1.2, 1.5 20, 22, 31.75, 32 5, 10
200 1.0, 1.2, 1.5, 1.6 20, 22, 31.75, 32 5, 10
250 1.0, 1.2, 1.5, 1.6, 1.8, 2.0 20, 22, 31.75, 32 5, 10
300 1.2, 1.5, 1.6, 1.8, 2.0 20, 22, 31.75, 32 10
350 1.5, 1.6, 1.8, 2.0, 2.2, 2.6, 3.0 20, 22, 31.75, 32 10
400 1.5, 1.6, 1.8, 2.0, 2.2, 2.6, 3.0 20, 22, 31.75, 32 10

Other sizes are available upon request.

Features:
High cutting efficiency
High abrasion resistance with longer life.
Better form stability

1A1R Diamond /CBN cutting Wheels Metal bond diamond cutting wheel 0
