Welcome to the world of Diamond and CBN Industrial Tools-Zhengzhou Shine Abrasives Co.,Ltd from China.
 |
| Place of Origin: | China |
| Brand Name: | Shine Abrasives |
| Certification: | ISO |
| Model Number: | 4V2 1A1 14A2 |
| Minimum Order Quantity: | 2 pcs |
|---|---|
| Price: | FOB |
| Packaging Details: | one in paperbox |
| Delivery Time: | 5 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 PCS in one week |
| Wheel Color: | Black | Thickness: | 20mm |
|---|---|---|---|
| Wheel Shape: | Round | Advantages: | High Working Efficiency |
| Color: | White | Type: | Abrasive Disc |
| Abrasive Grain: | Diamond | Quantity: | High |
| Style: | 1V1 | Max Operating Temperature: | Other |
| Max Feed: | 2m/s | Diamond Rim Size: | 5x3mm |
| Noise Level: | Low | Accuracy: | High |
| Package: | Customized | ||
| High Light: | Abrasive Cutting Disc,Diamond Cutting Disc |
||
Metal bond diamond cut off wheels with steel core is produced with high strength, high rigidity steel plate with sintered metal bonded abrasives layer. Compared with resin bond, the thickness is thinner with higher rigidity, suitable for deep cutting off or grooving.
| Diameter (D) | Abrasive Thickness (T/U) | Hole Diameter (H) | Abrasive Width (X) |
| 60, 75, 80 | 0.3, 0.5, 0.6 | 10, 20 | 5 |
| 100 | 0.5, 0.6, 0.8, 1.0, 1.2 | 10, 20, 22, 31.75, 32 | 5, 10 |
| 125 | 0.8, 1.0, 1.2, 1.5 | 20, 22, 31.75, 32 | 5, 10 |
| 150 | 0.8, 1.0, 1.2, 1.5 | 20, 22, 31.75, 32 | 5, 10 |
| 180 | 0.8, 1.0, 1.2, 1.5 | 20, 22, 31.75, 32 | 5, 10 |
| 200 | 1.0, 1.2, 1.5, 1.6 | 20, 22, 31.75, 32 | 5, 10 |
| 250 | 1.0, 1.2, 1.5, 1.6, 1.8, 2.0 | 20, 22, 31.75, 32 | 5, 10 |
| 300 | 1.2, 1.5, 1.6, 1.8, 2.0 | 20, 22, 31.75, 32 | 10 |
| 350 | 1.5, 1.6, 1.8, 2.0, 2.2, 2.6, 3.0 | 20, 22, 31.75, 32 | 10 |
| 400 | 1.5, 1.6, 1.8, 2.0, 2.2, 2.6, 3.0 | 20, 22, 31.75, 32 | 10 |
Other sizes are available upon request.
Our Cut-Off blades have below advantages:
1)High cutting speed
2)Free cutting action
3)Highly durable
4)Continuous uniformity and performance over time
5)Bonds available for both Wet cut and Dry Cut.
