50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability

50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability

  • 50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability
  • 50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability
  • 50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability
  • 50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability
50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 4V2 1A1 14A2
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: one in paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 PCS in one week
Contact Now
Detailed Product Description
Features: Resin+Diamond + Metal Abrasive: Diamond,CBN
Application: Grinding And Polishing Body Material: Aluminum Or Steel
Cutting Speed: High Ease Of Use: Easy
Edge Retention: High Hardness: Superhard
Material: Diamond Thickness: 10-50mm
Wheel Diameter: Varies Wheel Hole Size: 1-1.25 Inches
Wheel Price: FOB Wheel Speed: Customized
Wheel Structure: Varies
High Light:

50mm Thickness Diamond Resin Wheels

,

High Strength Diamond Resin Wheels

Diamond resin grinding wheels have high hardness, high strength and strong grinding ability

Diamond resin grinding wheels have high hardness, high strength and strong grinding ability. They are mainly used for grinding high and hard alloys, non-metallic materials, cutting hard and brittle carbide, non-metallic minerals, etc. Such as carbide, ceramics, agate, optical glass, semiconductor materials, wear-resistant cast iron, stone, etc.

Feature introduction

The diamond resin grinding wheel has a good polishing effect. The grinding wheel is sharp and not easy to clog during grinding. The specific characteristics are as follows:

50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability 0

1. The grinding efficiency is high and the grinding wheel consumption is relatively slow.

2. It has good self-sharpening properties, generates little heat during grinding, and is not easy to get clogged, which reduces the phenomenon of work burns during grinding.

3. The grinding wheel has a certain degree of elasticity, which is beneficial to improving the surface roughness of the workpiece. It is mainly used for fine grinding, semi-fine grinding, knife grinding, polishing and other processes.

4. The diamond resin grinding wheel is cured at low temperature, has a short production cycle, and relatively simple equipment and supply processes; because the resin is fluid, it is easy to form grinding wheels with complex surfaces.

Classification

Diamond resin grinding wheels (resin knife grinding wheels) can be selected according to product models (parallel grinding wheels, parallel arc grinding wheels, double-sided concave grinding wheels, double bevel grinding wheels, bowl-shaped grinding wheels), etc.

50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability 1

Their uses:

Parallel grinding wheel: Mainly used for cylindrical grinding and blade processing of carbide.

Parallel arc grinding wheel: mainly used for form grinding of cemented carbide and arc surface form grinding.

Double-sided concave grinding wheel: mainly used for grinding measuring tools and coreless grinding wheel machines.

Double bevel grinding wheel: mainly used for form grinding of carbide gear hobs and thread cutters.

Bowl-shaped grinding wheel: mainly used for sharpening carbide tools and high-speed steel tools, and can also be used for milling.

50mm Thickness Diamond Resin Wheels High Strength Strong Grinding Ability 2
