36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains

36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains

  • 36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains
  • 36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains
  • 36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains
  • 36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains
36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 4V2 1A1 14A2
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: one in paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 PCS in one week
Contact Now
Detailed Product Description
Arbor Hole: 1/2-1 Inch Bond: Customized
Color: Brown Customized Support: OEM, ODM
Diamond Rim Size: 125x10mm Feature: High Grinding Efficiency
Grade: Customized Grain Size: 36 Grit
Grit Range: 24-400 Hole: Customized
Maximum Operating Speed: 4140 RPM Structure: Customized
Wheel Diameter: 6 Inches Wheel Thickness: 1 Inch
Wheel Type: Type 1
High Light:

1 Inch Diamond Grinding Wheel

,

36 Grit Diamond Grinding Wheel

Diamond grinding wheel selection Compared with grinding wheels made of general abrasive grains

Compared with grinding wheels made of general abrasive grains such as boron carbide, silicon carbide, corundum, etc., diamond grinding wheels have sharper edges, less wear, longer life, high productivity, and good processing quality, but are expensive, so they are suitable for fine grinding of cemented carbide and ceramics. , semiconductors and other high-hardness, brittle, difficult-to-machine materials.

Characteristics of diamond grinding wheels include abrasive type, particle size, hardness, concentration, bond, and wheel shape and size.

Abrasives: Synthetic diamond (JR) is widely used. It is divided into various types according to its crystal shape and particle strength, and the type is selected according to its specific use.

36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains 0

Particle size: It should be comprehensively considered from three aspects: workpiece roughness, grinding productivity and diamond consumption.

Hardness: Only resin-bonded diamond grinding wheels have the property of "hardness". Generally, S (Y1) level or higher is used.

Binders: There are four commonly used binders. Their bonding ability and wear resistance are in the order of resin, ceramics, bronze, and electroplated metal. Resin bonded diamond grinding wheels have high grinding efficiency, good roughness of the workpiece to be processed, wide application range, good self-sharpening, not easy to block, low heat generation, easy to trim, and are mainly used in fine grinding processes. Ceramic bond diamond grinding wheels are mainly used for grinding various non-metallic hard and brittle materials, cemented carbide, superhard materials, etc.

Concentration: The concentration selection depends on the particle size, binder, shape, processing method, production efficiency and grinding wheel life requirements of the grinding wheel. High-concentration diamond grinding wheels have a strong ability to maintain the shape of the grinding wheel. When grinding with low-concentration grinding wheels, diamond consumption is often lower and should be selected according to needs.

Shape and size: Select according to the shape, size and machine tool conditions of the workpiece.

36 Grit 1 Inch Diamond Grinding Wheel Made Of General Abrasive Grains 1
