Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape

Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape

  • Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape
  • Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape
  • Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape
  • Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape
Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 4V2 1A1 14A2 6A2
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: one in paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 PCS in one week
Contact Now
Detailed Product Description
Abrasive Structure: Customized Alias: CBN Grinding Wheel, Crankshaft Grinding
Bond: Vitrified Bond Type: Vitrified
Coolant: Dry Feature: Long Life
Shape: Cylindrical Size: 6 Inch
Suitable: Inner Surface Viscosity: As Required
Wheel Features: High Efficiency Wheel Hole Diameter: Customized
Wheel Max Rpm: Standard Wheel Structure: Standard
Wheel Thickness: Standard
High Light:

Shine Abrasives Diamond Grinding Wheel

,

6 Inch Diamond Grinding Wheel

Shine Abrasives Vitrified Bond Diamond grinding wheel selection

Compared with grinding wheels made of general abrasive grains such as boron carbide, silicon carbide, corundum, etc., diamond grinding wheels have sharper edges, less wear, longer life, high productivity, and good processing quality, but are expensive, so they are suitable for fine grinding of cemented carbide and ceramics. , semiconductors and other high-hardness, brittle, difficult-to-machine materials.

Characteristics of diamond grinding wheels include abrasive type, particle size, hardness, concentration, bond, and wheel shape and size.

Abrasives: Synthetic diamond (JR) is widely used. It is divided into various types according to its crystal shape and particle strength, and the type is selected according to its specific use.

Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape 0

Particle size: It should be comprehensively considered from three aspects: workpiece roughness, grinding productivity and diamond consumption.

Hardness: Only resin-bonded diamond grinding wheels have the property of "hardness". Generally, S (Y1) level or higher is used.

Binders: There are four commonly used binders. Their bonding ability and wear resistance are in the order of resin, ceramics, bronze, and electroplated metal. Resin bonded diamond grinding wheels have high grinding efficiency, good roughness of the workpiece to be processed, wide application range, good self-sharpening, not easy to block, low heat generation, easy to trim, and are mainly used in fine grinding processes. Ceramic bond diamond grinding wheels are mainly used for grinding various non-metallic hard and brittle materials, cemented carbide, superhard materials, etc.

Concentration: The concentration selection depends on the particle size, binder, shape, processing method, production efficiency and grinding wheel life requirements of the grinding wheel. High-concentration diamond grinding wheels have a strong ability to maintain the shape of the grinding wheel. When grinding with low-concentration grinding wheels, diamond consumption is often lower and should be selected according to needs.

Shape and size: Select according to the shape, size and machine tool conditions of the workpiece.

Shine Abrasives Vitrified Bond Diamond Grinding Wheel 6 Inch Cylindrical Shape 1
