High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass

High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass

  • High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass
  • High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass
  • High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass
  • High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass
High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 1A1R
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: FOB
Packaging Details: ten pcs in paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 pcs in one week
Contact Now
Detailed Product Description
Application: Grinding Bond Type: Resin
Material: Diamond Packaging: Carton
Product Name: 1A1R Diamond Wheels Shape: Round
Surface Finish: Smooth Concentration: Superhard Ceramic Rod Plate
Diameter: Other Grit Size: 60-400
Hole Diameter: Other Max Operating Speed: Other
Max Operating Temperature: Other Thickness: Other
High Light:

high precision cutting slotting grinding wheel

,

1A1R resin bond diamond Wheels

,

1A1R Diamond Wheels For Ceramic Glass

1A1R resin bond diamond high precision cutting slotting grinding wheel for ceramic glass for induction cooker

1A1R Diamond Cutting Wheel

The 1A1R Special combines a steel core with the 1/4″ diamond or CBN section. The result is a highly rigid wheel primarily used for deeper cutting applications, which require additional wheel exposure. This wheel is used on standard surface grinders, OD grinders and machining centers. The 1A1R Special is available in 4″, 5″, 6″, 7″ and 8″ diameters. The thickness ranges from .032″ to .375″ in increments of .001″.
D(mm)
T(mm)
U(mm)
H(mm)
X(mm)
4” /100
1
0.8
31.75
10
5”/ 125
1
0.8
31.75
10
6”/ 150
0.8 / 1
0.6 / 0.8
31.75
10
8”/ 200
1
0.8
31.75
10
12”/ 300
1 / 1.5
1.3
31.75
10
16”/ 400
2
1.8
31.75
10



High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass 0

Diamond cut off wheels
For cutting carbide, glass, ceramic, sillicon, quartz, glass fiber plastics (GRP), graphite, QFN and ultra hard steel, etc
CBN cut off wheels
For cutting hardened steel, cast iron, HSS, magnetic materials, bearing steel and mould steel, etc

High Precision 1A1R Resin Bond Diamond Wheels Cutting Slotting Grinding For Ceramic Glass 1
