Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm

Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm

  • Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm
  • Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm
  • Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm
  • Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm
Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 1A1R
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: 5 pcs in one paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 pcs in one week
Contact Now
Detailed Product Description
Application: Grinding And Polishing Bond: Metal
Color: Silver Diameter: 6-16mm
Grit: 60-3000# Hole Size: 1-3mm
MOQ: 100 Pieces Material: Diamond
Packaging: Carton Box Processing Type: Resin Bond
Product Name: 1A1R Diamond Wheels Shape: Round
Thickness: 2-6mm
High Light:

1A1R Resin diamond cutting disc

,

1A1R diamond cutting disc

,

Silicon Carbide Ceramic Cutting Disc

1A1R Resin diamond cutting disc (silicon carbide ceramic cutting disc)

Silicon carbide ceramic cutting disc product specifications: 150*1.0*25.4

It can also be customized according to customer requirements. The small diameter can be 80mm and the diameter can be 400mm.

Precautions for cutting silicon carbide ceramic cutting discs:

1. Please check the silicon carbide ceramic cutting disc carefully before installing it. If there is a chip or other damage, please stop using it. ​

2. When the silicon carbide ceramic cutting disc is marked with a direction of rotation, it must be consistent with the direction of rotation of the machine tool. On the contrary, the cutting is not sharp and it is difficult to exert the performance of the cutting grinding wheel. ​

3. Please do not use silicon carbide ceramic cutting discs that do not meet the requirements

4. If any abnormality is found during the cutting process, the machine should be stopped immediately to investigate the cause. ​

5. When the cutting is not sharp, the silicon carbide ceramic cutting disc must be trimmed and sharpened. If you continue to use it, there is a possibility of overheating, overloading and damage to the grinding wheel. ​

6. When the silicon carbide ceramic cutting disc is rotating, it is strictly forbidden to use your hands for cutting, and you are not allowed to touch the grinding wheel with your hands and body.

7. Diamond ultra-thin cutting blades are strictly prohibited from being used for operations other than grooving or cutting to avoid abnormalities due to uneven stress.

Instructions for ordering silicon carbide ceramic cutting discs:

When customers choose silicon carbide ceramic cutting discs, they tell us the product specifications, diameter, thickness, aperture, etc., the requirements of the cutting products, rough cutting and fine cutting




Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm 0

Ceramic 1A1R Resin Diamond Cutting Disc Silicon Carbide 16mm 1
