11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide

11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide

  • 11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide
  • 11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide
  • 11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide
  • 11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide
11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 11V9
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: one in one paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 pcs in one week
Contact Now
Detailed Product Description
Application: Grinding And Cutting Arbor Hole: Varies
Availability: Widely Bond Type: Resin
Cutting Speed: High Diameter: Varies
Durability: High Finish: Smooth
Grit Size: Varies Material: Diamond
Max RPM: Varies Product Name: Resin Bond Diamond Wheels
Shape: Wheel Thickness: Varies
High Light:

cup shaped resin bond diamond wheels

,

11V9 resin bond diamond grinding wheels

,

diamond grinding wheels for tungsten carbide

11V9 cup shaped resin bond diamond grinding wheels for sharpening tungsten carbide

11v9 cup shaped resin bond diamond grinding wheels for sharpening tungsten carbide

resin bond diamond grinding wheels have features of good self-sharpening, low heat generated during grinding, not easy to block and reduces the phenomenon of working burns during grinding. Resin bond has a certain elasticity and is conducive to improving the roughness of the work piece surface, resin bond cup shaped diamond grinding wheels mainly used for fine grinding, semi-fine grinding, sharpening grinding, polishing and other processes. Therefore, diamond grinding wheels for tungsten carbide are widely used in the field of grinding and cutting.
11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide 0
cup shaped diamond grinding wheels used for sharpening and finishing of front surface of multiple-blade tools.The rim layer is made of synthetic diamond powder in metal, resin or vitrified bond.

D H X W
75 20 5-10 5-10
100 20 5-10 5-10
125 32 5-10 5-10
150 32 5-10 5-10
Other specification can be made according to customers requirements.



Shine Abrasives resin bond cup shaped diamond grinding wheels have strong competitive advantages in the processing fields of carbide tools, ceramics, glass, PCBN tools, PDC cutter, Steel, cast iron, electronic information components precision cutting etc.

11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide 1

11V9 Cup Shaped Resin Bond Diamond Grinding Wheels For Sharpening Tungsten Carbide 2
