Product Details:
Place of Origin: CHINA
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 1A1R
Payment & Shipping Terms:
Minimum Order Quantity: 2 PCS
Price: Negotiate
Packaging Details: 1 pcs in one paper box
Delivery Time: 5 working days
Payment Terms: L/C, T/T
Supply Ability: 10000 PCS per week
Contact Now
Detailed Product Description
Shape: 1A1R Type: Abrasive Disc
Bond: Resion Metal Bond Grit: #60-#220
High Light:

Diamond Bronze Sintered Cutting Disc

,

Resin Metal Bond CBN Grinding Wheel

,

CBN Grinding Wheel Glass Cutting Disc

Specification D (mm) T (mm) E(mm) H (mm) X (mm) Grit
1A1R 100x1.0x31.75x10mm 100 1 0.8 31.75 10 D126 or any other
1A1R 125x1.0x31.75x10mm 125 1 0.8 31.75 10 D126 or any other
1A1R 150x1.0x31.75x10mm 150 1 0.8 31.75 10 D126 or any other
1A1R 150x0.8x31.75x10mm 150 0.8 0.6 31.75 10 D126 or any other
1A1R 150x0.5x31.75x10mm 150 0.5 1 31.75 10 D126 or any other
1A1R 200x1.0x31.75x10mm 200 1 0.8 31.75 10 D126 or any other
1A1R 300x1.0x31.75x10mm 300 1 1.3 31.75 10 D126 or any other
1A1R 400x1.0x31.75x10mm 400 1 1.5 31.75 10 D126 or any other

Products Description:

Super thin Resin Metal Bond Diamond Bronze sintered cutting disc CBN grinding wheel Glass cutting disc

Our comapny developed Super thin 1A1R Diamond and CBN Wheels, which can be used for Cut-off, Cutting, Grooving, Slotting, Dicing and etc. Resin Bond and metal bond are available for different applications. Diameter can be 50mm to 400mm. Thickness is from 0.5mm to 2mm. Grits can be, D151, D181, D126, D107, D91, D76, D64, D46 and others. Cutting material can be: tungsten carbide, ceramic, glass, stone, Gem and gemstones, steel and many other materials.


Resin Metal Bond Diamond Bronze Sintered Cutting Disc CBN Grinding Wheel Glass Cutting Disc 0

Resin Metal Bond Diamond Bronze Sintered Cutting Disc CBN Grinding Wheel Glass Cutting Disc 1



Product Features.

1) Fast Cutting, improve cutting effeciency
2) Free of chipping, Excellent cutting surfaces and edges
3) High Precise Cutting and grooving, High accurancy.
4) Smooth cutting, no clipping of the blades
5) Much longer life than tradtional abrasive cutting wheels.
6) Customized design is available.

Notice
1. Before use, make sure that the grinding wheel is fixed in place and will not shake .
2. Use the grinding wheel at the required speed.
Resin bond 1A1rR diamond grinding wheels are compound of steel plate and superabrasive work layer. The steel plate has high
strength and high rigidity. ultra-thin cut off wheels are generally used for deep cutting and grooving.
Resin bond ultra-thin cut off wheels mainly used for slotting and cutting of ceramics, crystal, quartz, gems, carbide, magnetic
materials, electrical light wave glass tube and optical glass;
Resin bond CBN cutting wheels mainly used for slotting and cutting of tool steel, mould steel, bearing steel, heat resistance steel,stainless steel and cast iron.
