Name: 1A1 Resin Bond Diamond Wheel for Tungsten Carbide Tools OD Grinding
Brand: ZHENGZHOU SHINE ABRASIVES CO.,LTD
SKU: 4V2 1A1 14A2
Price: 50.00 USD
Availability: InStock

Home Products 1A1 Diamond Wheel

1A1 Resin Bond Diamond Wheel for Tungsten Carbide Tools OD Grinding

Product Details:

Place of Origin:	China
Brand Name:	Shine Abrasives
Certification:	ISO
Model Number:	4V2 1A1 14A2

Payment & Shipping Terms:

Minimum Order Quantity:	2 pcs
Price:	FOB
Packaging Details:	one in paperbox
Delivery Time:	5 work days
Payment Terms:	L/C, T/T
Supply Ability:	1000 PCS in one week

Contact Now

Detailed Product Description

Processing Method:	Sintering	Max Speed:	6,000 RPM
Grit Size:	30/40	Thickness:	10 Mm
Warranty:	1 Year	Arbor Hole Size:	1 Inch
Process:	Process	Country Of Origin:	China
Grinding Ability:	High	Wheelgrade:	Medium
Color:	Green, Red	Grain Size:	Customized
Wheel Shape:	Round	Diamond Rim Size:	38x20mm
Grit:	Customized
Highlight:	1A1 resin bond diamond wheel , diamond wheel for tungsten carbide , OD grinding diamond wheel

1A1 Resin Bond Diamond Wheel for Tungsten Carbide Tools OD Grinding

Shine Abrasives 1A1 250mm resin bond diamond wheel is specifically designed for the outer diameter (OD) grinding of tungsten carbide tools. This type of wheel is optimized for precision grinding and finishing of various tungsten carbide components, providing high efficiency and durability.The 1A1 shape is flat and disc-like, allowing for effective grinding of the outer diameter of tools, ensuring good contact and stability during the grinding process.

1A1 Resin Bond Diamond Wheel for Tungsten Carbide Tools OD Grinding 0

Type	1A1 Flat metal bond diamond grinding wheel
Concentration	50%,75%,125%,150%
Mesh	46#,60#,80#,100#,120#(coarse grinding); 120#,150#,180#,200#,240#(medium grinding); 280#,320#,400#,500#,600#(fine grinding); 800#,1000#,1200#,1500#,2000#,3000#(polishing)
Specification	D75-H10-T5-X10 D150-H19-X5-T5 D125-T10-X10-H20/31.75 D100-T10-X10-H20/31.75 D175-H127-X4-T5 D250-H40-X10-T3 D300-H127-X10-T40 D350-H127-T20-X10 D400-H127-T40-X10 D500-H203-X10-T32 Specification sizes can be customized
Application	ard alloy,high alumina porcelain,optical glass agate gemstone, semiconductor material,ceramics,stone,etc

The 250mm size provides a sufficient grinding surface, suitable for different grinding machines while allowing for efficient material removal.

The resin bond offers a balance of flexibility and strength, allowing the wheel to conform slightly to the workpiece surface, which helps reduce chipping and enhances overall performance.

1A1 Resin Bond Diamond Wheel for Tungsten Carbide Tools OD Grinding 1
