5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30

5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30

  • 5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30
  • 5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30
  • 5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30
  • 5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30
5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30
Product Details:
Place of Origin: China
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 4V2 1A1 14A2
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: FOB
Packaging Details: one in paperbox
Delivery Time: 5 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 PCS in one week
Contact Now
Detailed Product Description
Material: Cubic Boron Nitride Surface Finish: Smooth
Bonding Agent: Resin Manufacturer: CBN Sharpening Wheel Co.
Size: Required,Customized Abrasive: CBN
Outer Diameter: 200mm Wheel Type: Sharpening Wheel
Viscosity: As Required Durability: High
Thickness: 1 Inch Arbor Hole Size: 1 Inch
Tolerance: ±0.01mm Hole Size: 1/2 Inch
Surface Treatment: Polishing
High Light:

5 Inch CBN Grinding Wheel

,

Electroplated CBN Grinding Wheel

,

10/30 CBN Grinding Wheel

5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30

Electroplated CBN grinding wheel is specially used for band saw grinding. the electroplating process on the surface of CBN plated steel substrate can obtain precision, ensure high-quality tooth shape and sharpen the band saw blade.



Product Name: Electroplated CBN sharpening band saw wheel
Model: 5 inch / 6 inch / 8 inch
Material: high quality cubic boron nitride
Grinding wheel base material: steel
Band saw angle: WM 10/30,WM 13/29,WM 12/28,WM 9/29,WM 6/30,WM 7 / 39.5,Lenox 10/30
We can customize CBN grinding wheel according to the needs of customers



the characteristics of different angle band saw grinding wheels are as follows
10 / 30: common wheel profile, cork and hardwood band saw can be used;
9 / 29: band saw or hardwood band saw for winter wood cutting;
13 / 29: band saw or cork band saw for summer wood cutting;
4 / 32: band saw for very hard wood cutting;
7 / 34: for hardwood cutting band saw

5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30 0

5 Inch Electroplated CBN Grinding Wheel Sharpening Band Saw Wheel 10/30 1
