Electroplated Diamond Grinding Wheels 100mm 4'' Grinding Wheel Turning Tools Grinding

Electroplated diamond grinding wheels 100mm 4" grinding wheel turning tools grinding

Electroplated Grinding Wheel is a grinding wheel made by electrochemical method. The grinding wheel working layer contains diamond grinding particles, and the diamond abrasive is bonded to the substrate by a metal bond.Somebetter offers various Diamond /CBN Grinding Wheels, including Resin Bond , Metal Bond and Vitrified Diamond wheels.

Electroplated diamond grinding wheel can be used forgrinding and polishing hard and brittle materials, such ascemented carbide, ceramics, agate, optical glass,semiconductor materials, stone, etc.

The existing mechanism of action of rare earth elements in metal matrix/diamond composite materials is summarized as follows:

(1) Rare earth elements can react with impurities such as oxygen and sulfur in the matrix, improve the distribution of inclusions, and produce solid solution strengthening of the metal matrix;

(2) Rare earth elements can reduce the oxides on the metal surface during the sintering process, reduce the obstacles of the oxide film to atomic diffusion, accelerate atomic diffusion, and improve the bonding fluidity of the metal; promote the sintering process and activate sintering. ;
