Place of Origin: | China |
Brand Name: | Shine Abrasives |
Certification: | ISO |
Model Number: | 4V2 1A1 14A2 |
Minimum Order Quantity: | 2 pcs |
---|---|
Price: | FOB |
Packaging Details: | one in paperbox |
Delivery Time: | 5 work days |
Payment Terms: | L/C, T/T |
Supply Ability: | 1000 PCS in one week |
Abrasive: | Diamond,CBN,Required | Arbor Hole Size: | 1 Inch |
---|---|---|---|
Body Material: | Iron/aluminum/stainless Steel | Bond: | Electroplated |
Diameter: | 6 Inch | Grit Size: | 80/100/120/150/180/200/220/240/280/320/360/400/500/600/800 |
Hole: | 32mm | Hs Code: | 6804221000 |
Manufacturer: | CBN Sharpening Wheel Co., Ltd. | Quantity: | 1 |
Surface Finish: | Smooth | Thickness: | 1 Inch |
Tolerance: | ±0.01mm | Type: | Flat Wheel,Single Row |
Usage: | Dry Or Wet | ||
Highlight: | Electroplated CBN Grinding Wheel,V Shaped Tip CBN Grinding Wheel |
Electroplated diamond cbn wheel have the features of good self-sharpening, sharp cutting, high efficiency, low roughness of work piece surface, few heat generating and without burning work piece. They are suitable for high efficiency and precision grinding of most workpieces.
Abrasives
|
Diamond / CBN
|
||
Grit Size
|
Customized
|
||
Bonding Method
|
Electroplating / Resin Bonding / Vitrified Bonding / Metal Bonding
|
||
Body Material
|
Aluminum or Steel
|
||
Shape
|
Flat, Dish, Bowl, can be customized
|
||
Working Material
|
Tungsten Carbide, Ceramic, Cermet, Steel HRC, Glass and Others
|
||
Size of the wheel
|
Customized, (depend on the customer's design)
|
