Place of Origin: | CHINA |
Brand Name: | Shine Abrasives |
Certification: | ISO |
Model Number: | 10/30 |
Minimum Order Quantity: | 2 PCS |
---|---|
Price: | Negotiate |
Packaging Details: | 1 pcs in one paper box |
Delivery Time: | 5 working days |
Payment Terms: | L/C, T/T |
Supply Ability: | 5000 pcs per week |
Diameter: | 5 Inch 127mm | Bond: | Electroplated |
---|---|---|---|
Grit: | B151 | Profile: | 10/30 |
Tooth Spacing: | 22.2mm | HS Code: | 6804221000 |
Highlight: | Shine Abrasives Lenox CBN Sharpening Wheel,CBN Sharpening Wheel 127*22.2*12.7mm,127*22.2*12.7mm cbn abrasive wheels For Lenox |
CBN Sharpening Wheel 127x22.2x12.7mm For Lenox Band Saw Blades
Shine Abrasives 127mm diameter CBN wheels for Lenox 10/30 profile band saw blades sharpening
10/30 profile is the very popular band saw blades. 10/30 is usual also called 10° profile.
For band saw with tooth spacing is usual 7/8''=22.2mm. the wheel thickness is 22.2mm
the wheel bore sizes are usual 12.7mm of 1/2 inch.
The drawing of Shine Abrasives CBN Sharpening Wheel 127x22.2x12.7mm For Lenox Band Saw Blades
The size form of Shine Abrasives CBN Sharpening Wheel 127x22.2x12.7mm For Lenox Band Saw Blades
Abrasive Material:CBN | Bond Type:Electroplated |
CBN Grit:100# | Wheel Diameter:5''=127mm |
Wheel Bore:12.7m | Wheel Weight:1.6kgs/PC |
Wheel Thickness:22.2mm | Body Material: Steel |
Other sizes also are available as requested.
Package of Shine Abrasives CBN Sharpening Wheel 127x22.2x12.7mm For Lenox Band Saw Blades
Single wheel in one black color paper box as below picture.
10PCS Wheels are in one export carton.
Features of Shine Abrasvies CBN Sharpening Wheel 127x22.2x12.7mm For Lenox Band Saw Blades
Since the cubic boron nitride abrasive tool can maintain the sharpness of the abrasive micro-edge for a long time,
the machining accuracy and surface roughness value of the workpiece to be processed can achieve ideal results,
so the durability of the workpiece can be increased by 10%-30% . Therefore, even batch-machined workpieces will always obtain high shape, precision and consistency. CBN grinding wheel grinding can obtain high dimensional accuracy and low surface roughness,
the machined surface is not easy to produce cracks and burns, and the residual stress is small.
The quality of the machined surface is improved, generally there is no crack,
it is not easy to burn, and residual compressive stress can be obtained, which significantly improves the fatigue strength of the workpiece. Generally, the durability of the ground workpiece can be increased by 30-50%.
Application picture for reference
