1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing

1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing

  • 1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing
  • 1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing
  • 1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing
1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing
Product Details:
Place of Origin: CHINA
Brand Name: Shine Abrasives
Certification: ISO
Model Number: 10/30
Payment & Shipping Terms:
Minimum Order Quantity: 2 PCS
Price: Negotiate
Packaging Details: 1 pcs in one paper box
Delivery Time: 5 working days
Payment Terms: L/C, T/T
Supply Ability: 5000 pcs per week
Contact Now
Detailed Product Description
Diameter: 127 Bond: Electroplated
Grit: B151 Profile: WM10/30
Tooth Spacing: 3/4'' HS Code: 6804221000
High Light:

1.6kg 127mm Cubic Boron Nitride Grinding Wheel

,

cbn diamond wheel 3/4'' Tooth Spacing

,

1.6kg Cubic Boron Nitride Grinding Wheel

127mm CBN Sharpening Wheel For 3/4''Tooth Spacing Band Saw Blades



Shine Abrasives 5'' diameter CBN wheels for Wood Mizer 10/30 profile band saw blades sharpening

For band saw with tooth spacing is 3/4''=19.05mm. the wheel thickness is 19.05mm

the wheel bore sizes are usual 12.7mm of 1/2 inch.



Application of CBN grinding wheels:
Electroplated profile CBN grinding wheels are designed for sharpening band saws used in the wood, sawmill and food industry.

Due to the precise adjustment of the grinding wheel profile to the tooth profile,

high repeatability of the tooth geometry after sharpening is achieved, which guarantees a long service life of the saw.

The use of CBN galvanic grinding wheels when sharpening band saws enables high efficiency without the risk of burns.

CBN grinding wheels are used as abrasives

in high-performance grinding processes.

The shape of the CBN grinding wheel should closely match the outline of the band saw tooth.

Sharpening the saw with a grinding wheel, the shape of which differs from the tooth profile, is unacceptable and causes:

- rapid wear of the CBN grinding wheel;

- improper sharpening and, consequently, cracking of the saw



The drawing of Shine Abrasives 127mm CBN Sharpening Wheel For 3/4''Tooth Spacing Band Saw Blades

1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing 0

The size form of Shine Abrasives 127mm CBN Sharpening Wheel For 3/4''Tooth Spacing Band Saw Blades

Abrasive Material:CBN Bond Type:Electroplated
CBN Grit:100# Wheel Diameter:127mm
Wheel Bore:12.7m Wheel Weight:1.6kgs/PC
Wheel Thickness:19.05mm Body Material: Steel

Other sizes also are available as requested.



Package of Shine Abrasives 127mm CBN Sharpening Wheel For 3/4''Tooth Spacing Band Saw Blades
Single wheel in one black color paper box as below picture.
10PCS Wheels are in one export carton.



1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing 1



Features of Shine Abrasvies 127mm CBN Sharpening Wheel For 3/4''Tooth Spacing Band Saw Blades

Wheels with high grinding or sharpening speed.

Good finishing after grinding or sharpening.
Wheels with Longer life than traditional grinding wheels
Cost-effective



Application picture for reference

1.6kg 127mm Cubic Boron Nitride Grinding Wheel 3/4'' Tooth Spacing 2
